- Rated for system pressure up to 20,000 psi
- Displays in multiple units: psi, bar, mPA, kg/cm (user selectable)
- Zero reset - ensures that gauge reads actual system pressure
- Batteries included, condition indicator on readout
- IP65 rated case design
- Shut off selectable - menu driven
- UL listed, CE and RoHS compliant
Unit of Measure
Pressure Rating Range |
N/A 0-20,000 psi 0-1,380 bar 0-140 MPa 0-1400 Kg/cm |
Pressure Rating Interval |
N/A 1 psi 0.07 bar 0.01MPa .07 Kg/cm |
Weight |
N/A 0.5 Pound |
Accuracy, % of full scale |
N/A ± .025% |
Ship Weight |
N/A 1 lbs. |
