- 9 Models
- High flow quality couplers.
- Collar threads designed for full load.
- Base & piston mountings for easy fixturing.
- Removable load caps for flexibility & safety.
- Stop rings for piston blow-out protection.
- Plated piston to resist scoring & corrosion.
- Large bearings resist side load.
- Rod wiper protects inner cylinder from dirt.
- Removable carrying handles included on models R556 through R10010.
- Power Pumps are suggested for these unit
Unit of Measure
Capacity |
N/A 75 tons |
Stroke |
N/A 13.125 inches |
Minimum Height - A |
N/A 19 3/8 inches |
Extended Height - B |
N/A 32 1/2 inches |
Ram Bore Diameter |
N/A 4 1/2 inches |
Effect Area |
N/A 15.90 sq. inch |
Pressure at Capacity |
N/A 9430 psi |
Oil Capacity Required |
N/A 208.0 cu. inch |
Body O.D. - C |
N/A 5 3/4 inches |
Piston O.D. - D |
N/A 3 3/4 inches |
Base to Port C/L - E |
N/A 1 3/16 inches |
Collar Threads - G |
N/A 5 3/4 x 12 inches |
Collar Thread Length -G |
N/A 1 3/4 inches |
Weight |
N/A 130.0 lbs. |
Suggested Hand Pump |
N/A None - A power pump is suggested |
