- Industrial lifting and pushing applications.
- Choose from this complete line of premium–quality, standard bottle jacks. Ideal for use in any number of industrial lifting and pushing applications.
- The 9110B, 9015B, 9022B and 9033B feature a beveled base which allows the jack to “follow” the load, reducing the chance of dangerous side loading.
- Many jacks feature screw extensions and all can be used in the vertical, angled or horizontal positions.
- Serrated or contoured saddles help stabilize the load for a safer lift.
- All jacks meet ASME B30.1 standards and carry the Power Team Marathon Lifetime Warranty.
- 110 ton jack features dual pumps for time-saving two speed operation.
Unit of Measure
Capacity |
N/A 30 tons |
Stroke |
N/A 6.25 inches |
Retracted Height Min. |
N/A 11 inches |
Height With Screw Ext. |
N/A 17 1/4 inches |
No. Pump Strokes to Ext. Piston |
N/A 35 inches |
Saddle Diameter |
N/A 2 3/8 inches |
Base Size |
N/A 7 9/16 inches x 5 9/16 inches |
Pump Handle Length |
N/A 39 3/8 inches |
Handle Effort at Rated Capacity |
N/A 50 lbs. |
Carry Handle |
N/A Available |
Product Weight |
N/A 41.2 lbs. |
Ship Weight |
N/A 44 lbs. |
Standard Pack Qty |
N/A 2 |
