- Two-speed operation for reduced operator fatigue (except P-39)
- 4-way valving on the P-84 and P-464 for operation of double-acting cylinders
- External load release valve on remaining models for single-acting cylinder operation
- Internal pressure relief valve for overload protection
- Large oil capacity to power a wide range of cylinders or tools
- Contact Enerpac for applications where operating pressure is less than 10% of pressure rating.
Unit of Measure
Pump Type |
N/A Two speed |
Usable Oil Capacity |
N/A 453 cu. inch |
Pressure Rating - 1st Stage |
N/A 200 psi |
Pressure Rating - 2nd Stage |
N/A 10000 psi |
Oil Displacement per Stroke - 1st Stage |
N/A 7.69 cu. inch |
Oil Displacement per Stroke - 2nd Stage |
N/A 0.29 cu. inch |
Maximum Handle Effort |
N/A 110 lbs. |
Piston Stroke |
N/A 1.50 inches |
Dimension A |
N/A 8.25 inches |
Dimension B |
N/A 12.13 inches |
Dimension C |
N/A 6.42 inches |
Dimension D |
N/A 12.63 inches |
Dimension E |
N/A 7.68 inches |
Dimension H |
N/A 26.44 inches |
Dimension J |
N/A 0.98 inches |
Dimension L |
N/A 10.63 inches |
Dimension M |
N/A 6.89 inches |
Dimension N |
N/A 25.6 inches |
Dimension P |
N/A 3.63 inches |
Dimension S |
N/A 3.13 inches |
Weight |
N/A 61 lbs. |
Ship Weight |
N/A 64 lbs. |
