- Compact and ergonomic design, easy to use
- Unique angled head allows flush access
- Single-acting, spring return cylinder
- Heavy-duty chisels can be reground
- Applications include servicing trucks, piping industry, tank cleaning, petrochemical, steel construction and mining
- Maximum allowable hardness to split is HRc-44.
- Not to be used on square nuts.
Unit of Measure
Hexagon Nut Range |
N/A 0.94 - 1.13 inches |
Maximum Operating Pressure |
N/A 10000 psi |
Bolt Range |
N/A 0.63 - 0.88 inches |
Capacity |
N/A 15 tons |
Oil Capacity |
N/A 3.66 cu. inch |
Dimension A |
N/A 2.60 inches |
Dimension B |
N/A 10.24 inches |
Dimension C |
N/A 0.39 inches |
Dimension D |
N/A 1.22 inches |
Dimension F |
N/A 1.93 inches |
Dimension H |
N/A 2.99 inches |
Dimension J |
N/A 1.30 inches |
Replacement Chisel Model No. |
N/A NCB-2432 |
Weight |
N/A 6.6 lbs. |
Ship Weight |
N/A 12 lbs. |
