- Features Z-Class high-efficiency pump design; higher oil flow and bypass pressure, cooler running and requires 18% less current draw than comparable pumps
- Powerful 1.7 hp universal electric motor provides high power-to-weight ratio and excellent low-voltage operating characteristics
- High-strength, molded composite shroud protects motor and electronics, while providing an ergonomic, non-conductive handle for easy transport
- Low-voltage pendant provides additional safety for the operator (remote control units)
- LCD readout provides pressure display and a number of diagnostic and readout capabilities never before offered on a portable electric pump
- Auto cycle feature provides continuous cycle operation of the torque wrench as long as the advance button is pressed. (Pump can be used with or without auto cycle feature).
- All models meet CE safety requirements and all CSA requirements.
- Subtract 7.7 lbs per gallon for competitive weight comparison.
Unit of Measure
Maximum Operating Pressure |
N/A 10,000 psi |
For Use With |
N/A Enerpac Torque Wrenches |
Usable Oil Capacity |
N/A 1.75 Gallon |
Motor Size |
N/A 1.7 hp |
Motor Voltage |
N/A 115 V |
Duty Cycle |
N/A Intermittent |
Valve Operation |
N/A Solenoid |
Valve Type |
N/A 4-Way, 2-Position |
Pump Control |
N/A Pendant |
Motor Specifications |
N/A 115 V, 1 Ph, 50/60 Hz |
Weight |
N/A 76 lbs. |
