- "Dial-in" feature on HNS150 makes adjustment of splitter simple, without the worry of damaging the bolt.
- Specially designed "tool steel" cutter blade penetrates the nut to the precise point where it cracks, stopping short of the bolt threads.
- Nut splitter features a dramatically improved cutter blade with an 800% greater resistance to chipping and breaking over previous models.
- All models feature a rugged one-piece cutting frame coupled to a heavy-duty hydraulic cylinder.
- Compact size allows you to use it in confined areas where it will deliver enough force to split the toughest "fused" or rusted-on grade 2H nuts.
- Simply split nut on one side, spin nut splitter 1/2 turn and make second cut on opposite side; nut separates into halves for easy removal.
Unit of Measure
Capacity |
N/A 15 tons25 tons |
Dimension A |
N/A 4.25 inches |
Dimension B |
N/A 6 inches |
Dimension C |
N/A 14.375 inches |
Dimension D |
N/A 3.875 inches |
Dimension F |
N/A 3.25 inches |
Head Thickness |
N/A 1.5 inches |
Replacement Blade |
N/A 308022 |
Tool Weight |
N/A 29 lbs. |
Ship Weight |
N/A 30.7 lbs. |
Standard Pack Qty |
N/A 1 |
