Roll Frame Presses
Enerpac Presses & Shop Equipment
- Quality welded frame for maximum strength and long life
- Frame rolls easily on 4 steel roller bearings
- Hydraulic clamp cylinders lock frame into position
- Exclusive “Hydra-Lift” bolster for effortless adjustment of the vertical daylight
- Standard roller head design allows movement of the cylinder from side to side
- All models in the Quick Selection Chart have been matched to a pump, cylinder, hoses and gauge, offering the complete package
- Roll Frame design features a stationary bed with the ability to support heavy loads
Item # |
Press Capacity |
Vertical Daylight A (Max.) |
Vertical Daylight A (Min.) |
Horizontal Daylight E |
Pump Model No. |
Price |
Add To Cart/Request Quote |
|---|---|---|---|---|---|---|---|
| IPR-5075 IPR-5075/Asset/IPR5075.jpg | Press Capacity N/A 50 tons | Vertical Daylight A (Max.) N/A 37.12 inches | Vertical Daylight A (Min.) N/A 6 inches | Horizontal Daylight E N/A 28.75 inches | Pump Model No. N/A GPER-3420BN | $59,417.10 |
Add To Cart
Request Quote |
| IPR-10075 IPR-10075/Asset/IPR10075.jpg | Press Capacity N/A 100 tons | Vertical Daylight A (Max.) N/A 41.28 inches | Vertical Daylight A (Min.) N/A 6.28 inches | Horizontal Daylight E N/A 35 inches | Pump Model No. N/A GPER-5420GN | $76,949.85 |
Add To Cart
Request Quote |
| IPR-20075 IPR-20075/Asset/IPR20075.jpg | Press Capacity N/A 200 tons | Vertical Daylight A (Max.) N/A 51 inches | Vertical Daylight A (Min.) N/A 11 inches | Horizontal Daylight E N/A 48 inches | Pump Model No. N/A GPER-5420GN | $136,365.84 |
Add To Cart
Request Quote |
